This hygienic temperature sensor for the food, pharma and biotech industries offers easy installation, high measurement confidence and a low cost of ownership.
Key benefits
Accelerate hygienic installation
The clamp-on design allows for quick, welding-free mounting directly onto your pipes. This eliminates the need for process interruptions and prevents dead spaces, helping to ensure a perfectly hygienic, unobstructed line.
Lower total cost of ownership
Thanks to a modular assembly and replaceable measuring inserts, maintenance and recalibration are fast and straightforward. Service the sensor without breaking the process seal, significantly reducing downtime and costs.
Improve measurement confidence
The clamp-on version features a silver measuring element pressed against the pipe by a spring. This enables optimal thermal contact and a fast 4-second response time for highly accurate, reproducible temperature monitoring.
Key details
| Output | Direct sensor signal; 4…20 mA (TH100/TH320); HART (TH320/TH420); PA (TH420) |
| Max. operation temperature | In the pipe: –30 … +300 °C (–22 … +572 °F); Clamp-on: –20 … +160 °C (–4 … 320 °F) |
| Ingress protection | IP65 (IP54 for some type of connection heads) |
| Approvals | SIL 2/3; ATEX |
